Replacement Dental Lamps

The Ultraviolet light is classified in three ranges of wavelength:
UV-A from 315nm to 400nm
UV-B from 280nm to 315nm
UV-C from 100nm to 280nm

We can offer UV-A 360nm and Germicidal Lamps 254nm that is part of UV-C.

UV-C Cold Cathode 254nm Germicidal Lamps
UV-C 254nm lamps are manufactured with quartz glass and have traces of Mercury –(less than 3mg per lamp). These lamps generate UV radiation at 254nm. There is also a very small amount of Ozone generated by the residual radiation of 185nm and corona effect.



CAUTIONS
• We recommend all suitable precaution to avoid eyes or skin exposure to UV radiation. It can produce serious damage to the eye, which may lead to temporary or permanent vision impairment. For this reason, the light produced by a germicidal lamp must be carefully shielded against both direct viewing and reflections and dispersed light that might be viewed.

• Do not look straight to the light. Use protective eyewear during operation.

• This UV radiation generated by this lamp is in risk group 1per ANSI or ESNA standard RP-27.3-96.

• Take also all suitable requirements recommended by the government safety code to avoid exposure to UV radiation or to a prolong inhalation of Ozone.

• Although our lamps are built with hard glass, there is a very small trace of Ozone generated by oxygen exposed to UV.

• When Lamp in use we recommend an adequate ventilation.

• Do not touch the lamp glass with the bare hands.

• Use appropriate protection, wires and insulated materials to avoid surge voltage from the lamp leads.

• Discard the lamps in accordance with safety code requirements.

• This lamp should not be used for cosmetic treatments, therapeutic or diagnostic purpose.

• Do not disassemble the ballast for any reason.

• Do not operate in presence flammable or explosive materials, liquid or fume.

• Intended for indoor use only. Do not use the ballast in wet or dump conditions.

• Do not expose/use lamp, ballast and wires in excessive heat, moisture, humidity, condensation, and other weather elements.

• Only our 6W, 8W and 10W lamp with vial (quartz tubing protected water sleeve) can be exposed to water/moisture up to the white ring. Do not use the ballast, wires, and lamp end/threaded flange in wet or dump conditions. If water gets into the lamp connections, the lamp will fail permanently, and it may be a fire hazard.

• This product is not a toy. Use and store out of reach of children


INSTRUCTIONS:

• Only qualified personnel should handle them.
• Use appropriate protection, wires and insulated materials to avoid surge voltage from the lamp leads.
• Do not touch the inverter or auxiliary circuits during operation. You are working with a high voltage device.

Hot Filament UV Lamps and Kits Currently in Stock

6W Germicidal UV 254nm Hot Filament inside Quartz Tubing 120V Ballast Kit for Air & Water Purification
Light Length: 135mm
Lamp Length: 212mm
Overall Length(Lamp & Fixture): Max 275mm
Lamp Dia: 23mm
UV Output @ 1cm distance: 5000µW/cm²
Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box
Thread Base: 35mm
Wire length from lamp to ballast: Min 425mm
Wire length from lamp to outley: Min 1250mm
Supplied Voltage: 120V AC
Part Number: MHFL-UV-6WK
OUT OF STOCK


6W Germicidal UV 254nm Hot Filament Replacement Lamp
Light Length: 135mm
Lamp Length: 212mm
Lamp Dia: 23mm
Watts: 6
UV Output @ 1cm distance: 5000µW/cm²

Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box

OUT OF STOCK


8W Germicidal UV 254nm Hot Filament inside Quartz Tubing 120V Ballast Kit for Air & Water Purification
Light Length: 215mm
Lamp Length: 298mm
Overall Length(Lamp & Fixture): Max 345mm
Lamp Dia: 23mm
UV Output @ 1cm distance: 6000µW/cm²
Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box
Thread Base: 35mm
Wire length from lamp to ballast: Min 425mm
Wire length from lamp to outley: Min 1250mm
Supplied Voltage: 120V AC
Part Number: MHFL-UV-8WK
OUT OF STOCK


8W Germicidal UV 254nm Hot Filament Replacement Lamp
Light Length: 215mm
Lamp Length: 298mm
Lamp Dia: 23mm
UV Output @ 1cm distance: 6000µW/cm²
Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box

OUT OF STOCK

10W Germicidal UV 254nm Hot Filament inside Quartz Tubing 120V Ballast Kit for Air & Water Purification.
Light Length: 250mm
Lamp Length: 332mm
Overall Length(Lamp & Fixture): Max 390mm
Lamp Dia: 23mm
UV Output @ 1cm distance: 7000µW/cm²
Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box
Thread Base: 35mm
Wire length from lamp to ballast: Min 425mm
Wire length from lamp to outley: Min 1250mm
Supplied Voltage: 120V AC
Part Number: MHFL-UV-10WK
OUT OF STOCK


10W Germicidal UV 254nm Hot Filament Replacement Lamp
Light Length: 250mm
Lamp Length: 332mm
Lamp Dia: 23mm
UV Output @ 1cm distance: 7000µW/cm²
Pin Length: 8mm
Base Type: T5F Pins Conf. Square Box

SOLD OUT

9W G23 UV-A 360nm Lamp & 120V AC Ballast Kit
Lamp Specifications:
Length - Inches: 6.50
Length - Millimeters: 165
Watts: 9 W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
Ballast: 120V AC with socket and attached wires & holder

DISCONTINUED


9W G23 UV-A 360nm Lamp
Lamp Specifications:
Length - Inches: 6.50
Length - Millimeters: 165
Watts: 9 W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
DISCONTINUED


9W UV-C 254nm Lamp & 120V AC Ballast Kit for Air Purification
Lamp Specifications:
Length - Inches: 6.50
Length - Millimeters: 165
Watts: 9 W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
Ballast: 120V AC with socket and attached wires & holder

OUT OF STOCK (expected back in stock 6/10/2020)


9W G23 Germicidal UV-C 254nm Lamp
Lamp Specifications:
Length - Inches: 6.50
Length - Millimeters: 165
Watts: 9 W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
OUT OF STOCK


11W UV-C 254nm Lamp & 120V AC Ballast Kit for Air Purification
Lamp Specifications:
Length - Inches: 9 1/4"
Length - Millimeters: 235mm
Watts: 11W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
Low-pressure mercury arc lamp
Ballast: 120V AC with socket and attached wires & holder

OUT OF STOCK (expected back in stock 6/10/2020)



11W G32 Germicidal UV 254nm Lamp
Lamp Specifications:
Length - Inches: 9 1/4"
Length - Millimeters: 235mm
Watts: 11W
Base: G23
Pins: 2
Bulb Life: 9000Hrs
Low-pressure mercury arc lamp
SOLD OUT


18W UV-C 254nm Lamp & 120V AC Ballast Kit for Air Purification
Lamp Specifications:
Low-pressure mercury arc lamp
Length - Inches: 8.9"
Watts: 18W
Volts: 60V
Base: 2G11
Bulb Shape: Single Tube 4-Pin
UV-C Radiation: 60µW/cm²
Bulb Life: 9000Hrs
Ballast: 120V AC with socket and attached wires & holder
OUT OF STOCK (expected back in stock 6/10/2020)


18W 2G11 Germicidal UV 254nm Lamp
Lamp Specifications:
Low-pressure mercury arc lamp
Length - Inches: 8.9"
Watts: 18W
Volts: 60V
Base: 2G11
Bulb Shape: Single Tube 4-Pin
UV-C Radiation: 60µW/cm²
Bulb Life: 9000Hrs
SOLD OUT


24W UV-C 254nm Lamp & 120V AC Ballast Kit for Air Purification
Lamp Specifications:
Low-pressure mercury arc lamp
Overlall
Length Approx.12.5"
Watts: 24W
Base: 2G11
Bulb Shape: Single Tube 4-Pin
UV-C Radiation: 60µW/cm²
Life: 9000Hrs
Ballast: 120V AC with socket and attached wires & holder
SOLD OUT


24W 2G11 Germicidal UV 254nm Lamp
Lamp Specifications:
L
ow-pressure mercury arc lamp
Overlall
Length Approx.12.5"
Watts: 24W
Base: 2G11
Bulb Shape: Single Tube 4-Pin
UV-C Radiation: 60µW/cm²
Bulb Life: 9000Hrs
SOLD OUT







36W UV-C 254nm Lamp & 120V AC Ballast Kit for Air Purification
Lamp Specifications:
Low-pressure mercury arc lamp
Length - Inches: 16.4"
Watts: 36W
Volts: 105V
Base: 2G11
Bulb Shape: H-Type Biax 4-Pin
UV-C Radiation: 120µW/cm²
Bulb Life: 9000Hrs
Ballast: 120V AC with socket and attached wires & holder
OUT OF STOCK (expected back in stock 6/10/2020)

36W 2G11 Germicidal UV 254nm Lamp
Lamp Specifications:
Low-pressure mercury arc lamp
Length - Inches: 16.4"
Watts: 36W
Volts: 105V
Base: 2G11
Bulb Shape: H-Type Biax 4-Pin
UV-C Radiation: 120µW/cm²
Bulb Life: 9000Hrs
OUT OF STOCK
